Lead-acid Battery Locomotive
Lead-acid battery locomotive adopts lead-acid battery as power source. It is designed for subway and tunnel shield construction withstanding harsh construction environment such as track conditions, steep slope and humidity, and can be matched with shield machine and gantry crane to greatly improve the construction efficiency. Its performance indicators are at the advanced level in the industry.
With its outstanding performance and reliability, it provides an efficient and environmentally friendly solution for mining transportation. We provide comprehensive life cycle services, from design to power system supply, from installation and commissioning to after-sales service training, as well as spare parts supply and technical support. Welcome to visit our website or contact our sales team for the latest product information and technical support.
General Specifications of Lead-acid Battery Locomotive Series
| Self-weight: | 45 - 65 T |
| Track Gauge: | 762/900mm |
| Wheelbase: |
2600mm |
| Min.Turning Curve: |
25m |
| Wheel Diameter: |
840mm |
| Motor Power: | 110 kW*2 - 180 kW * 2 |
| Battery Capactiy: |
630Ah - 800 Ah |
| Rated Voltage: | 540V |
| Houry Traction: | 89kN - 130 kN |
| Max,Traction: | 115kN - 165 kN |
| Houry Speed: |
8.9km/h - 10 km/h |
Engine Model |
Self-weight |
Track Gauge |
Engine Model |
Adhesive Weight |
Track Gauge |
||
| CTY45/7,9GP | 45 T | 762/900mm | CTY50/7,9GP | 50 T | 762/900mm | ||
| CTY55/7,9GP | 55 T | 762/900mm | CTY60/7,9GP | 60 T | 762/900mm | ||
| CTY65/7,9GP | 65 T | 762/900mm | |||||
| ——END—— | |||||||
RailMac Lead-acid Battery Locomotive Series Underground Mining Train
This is the list of all series of RailMac Lead-acid Battery Locomotive Series Underground Mining Train.
RailMac CTY65/7,9GP Underground Mining Train
RailMac Model: CTY65/7,9GP
Self Weight: 65T
Track Gauge: 762 or 900 mm
Wheelbase: 2600 mm
Min.Tuming Curve: 25 m
Wheel Diameter: 840 mm
RailMac CTY60/7,9GP Underground Mining Train
RailMac Model: CTY60/7,9GP
Self Weight: 60T
Track Gauge: 762 or 900 mm
Wheelbase: 2600 mm
Min.Tuming Curve: 25 m
Wheel Diameter: 840 mm
RailMac CTY55/7,9GP Underground Mining Train
RailMac Model: CTY55/7,9GP
Self Weight: 55T
Track Gauge: 762 or 900 mm
Wheelbase: 2600 mm
Min.Tuming Curve: 25 m
Wheel Diameter: 840 mm
RailMac CTY50/7,9GP Underground Mining Train
RailMac Model: CTY50/7,9GP
Self Weight: 50T
Track Gauge: 762 or 900 mm
Wheelbase: 2600 mm
Min.Tuming Curve: 25 m
Wheel Diameter: 840 mm
RailMac CTY45/7,9GP Underground Mining Train
RailMac Model: CTY45/7,9GP
Self Weight: 45T
Track Gauge: 762 or 900 mm
Wheelbase: 2600 mm
Min.Tuming Curve: 25 m
Wheel Diameter: 840 mm
