5T Battery Locomotive
The 5T Battery Locomotive is a viscous weight of 5 tons, adapted to 600, 762 or 900 mm gauge, traction force of 7.06 kN, the maximum traction force of up to 12.26 kN, the speed of 7 km / h. The power supply unit voltage of 90 V, the capacity of 330Ah, the power of the motor is 7.5 kW × 2.
It is a kind of equipment suitable for small mine transportation and small and medium-sized mine shunting. The locomotive is characterized by small external dimensions, short wheelbase, compactness and flexibility, fast and reliable rising brake, simple structure and convenient maintenance.
With its outstanding performance and reliability, it provides an efficient and environmentally friendly solution for mining transportation. We provide comprehensive life cycle services, from design to power system supply, from installation and commissioning to after-sales service training, as well as spare parts supply and technical support. Welcome to visit our website or contact our sales team for the latest product information and technical support.
General Specifications of 5T Battery Locomotive Series
| Adhesive Weight: | 5 tons |
| Track Gauge: | 600, 762 or 900 mm |
| Hourly System Traction: |
7.06 kN |
| Max. Traction: |
12.26 kN |
| Hourly System Speed: |
7 km/h |
| Supply Voltage: | 90 V |
| Capacity of Traction Battery: |
308 or 330 Ah (5 hours capacity) |
| Power of Electric Motor: | 7.5 kW * 2 |
| Wheelbase: | 850 mm |
| Speed Regulating Mode: | Resistance or IGBT |
Engine Model |
Adhesive Weight |
Track Gauge |
Engine Model |
Adhesive Weight |
Track Gauge |
||
| CTY5/6,7,9G(B) | 5 tons | 600, 762 or 900 mm | |||||
| ——END—— | |||||||
RailMac 5T Battery Locomotive Series Open Pit Mining Battery Train
This is the list of all series of RailMac 5T Battery Locomotive Series Open Pit Mining Battery Train.
RailMac CTY5/6,7,9G(B) Open Pit Mining Battery Train
RailMac Model: CTY5/6,7,9G(B)
Adhesive Weight: 5 tons
Track Gauge: 600, 762 or 900 mm
Hourly System Traction: 7.06 kN
Max. Traction: 12.26 kN
Hourly System Speed: 7 km/h
