20T Wire Diesel-Electric Iocomotive
The 20T Wire Diesel-Electric Locomotive is a specially designed compact railway traction equipment for specific scenarios, playing a vital role in fields like mine tunnel transportation. The wheel diameter is φ840 mm and the wheel gauge is 2500 mm, allowing the locomotive to run flexibly on narrow-gauge railways with smaller wheel size and shorter wheel gauge. It adopts a diesel-electric hybrid drive system where the diesel engine acts as the prime mover to drive the generator, converting diesel’s chemical energy into electrical energy that powers the traction motor to drive the wheels, combining the power advantages of a diesel engine with the flexibility of electric drive. With an adhesive weight of 20 tons, it can travel on 600 mm, 762 mm, or 900 mm narrow-gauge tracks, featuring an hourly-rated traction force of 39.23 kN and a maximum traction force of 49,50.96 kN to haul ore wagons or other cargo through tunnels.
With its outstanding performance and reliability, it provides an efficient and environmentally friendly solution for mining transportation. We provide comprehensive life cycle services, from design to power system supply, from installation and commissioning to after-sales service training, as well as spare parts supply and technical support. Welcome to visit our website or contact our sales team for the latest product information and technical support.
General Specifications of 20T Wire Diesel-Electric Iocomotive Series
| Curb Weight: | 20 tons |
| Track Gauge: | 600 , 762 or 900 mm |
| Traction Force: |
39.23 kN |
| Speed: |
15 km/h |
| Maximum Traction Force: |
49,50.96 kN |
| DC Voltage: | 550 V |
| Wheelbase: |
2500 mm |
Vehicle Model |
Curb Weight |
Towing Force |
Vehicle Model |
Curb Weight |
Towing Force |
||
| CJY20/6、7、9GB | 20 tons | 39.23 kN | CJY20/6、7、9GP | 20 tons | 39.23 kN | ||
| ——END—— | |||||||
RailMac 20T Wire Diesel-Electric Iocomotive Series Underground Mining Electric Locomotive
This is the list of all series of RailMac 20T Wire Diesel-Electric Iocomotive Series Underground Mining Electric Locomotive.
CJY20/6、7、9GP Underground Mining Electric Locomotive
RailMac Model: CJY20/6、7、9GP
Curb Weight: 20 tons
Towing Force: 39.23 kN
Speed: 15 km/h
Maximum Towing Force: 50.96 kN
CJY20/6、7、9GB Underground Mining Electric Locomotive
RailMac Model: CJY20/6、7、9GB
Curb Weight: 20 tons
Towing Force: 39.23 kN
Speed: 15 km/h
Maximum Towing Force: 49 kN
