Grout Car
Grout Car is composed of running gear, car body, power transmission system, mixing system, electrical control system and other parts. The mixing motor, gearbox and mixing shaft are directly connected, and the structure is compact. The running device adopts a two-axle with axle box, and it is a bearing mechanical transmission without bogie. The power system adopts twostage speed reduction box. The stirring shaft system can realize clockwise and counterclockwise rotation. The seal of the mixing shaft at both ends of the vehicle body is a labyrinth seal, and the mixing shaft can be taken out and replaced as a whole.
With its outstanding performance and reliability, it provides an efficient and environmentally friendly solution for mining transportation. We provide comprehensive life cycle services, from design to power system supply, from installation and commissioning to after-sales service training, as well as spare parts supply and technical support. Welcome to visit our website or contact our sales team for the latest product information and technical support.
General Specifications of Grout Car Series
| Dimensions: | 4131mm*1200mm*1800mm |
| Track Gauge: | 762/900mm |
| Operating Weight: |
6T |
| Wheelbase: |
1200mm |
| Wheel Diameter: |
440mm |
| Height of Traction: | 430mm |
| Agitator Tank: |
Vertical type |
| Total Capacity: | 3 cubic metre |
| Agitator Motor: | 7.5 kW |
| Sealing Mode of Stirring Shaft: | Labyrinth Seal, Automatic greasing when stirring |
| Stirring Blade Speed: |
13 r/min |
Engine Model |
Dimensions |
Track Gauge |
Engine Model |
Dimensions |
Track Gauge |
||
| SLSJ-3 | 4131mm*1200mm*1800mm | 762/900mm | |||||
| ——END—— | |||||||
RailMac Grout Car Series Underground Mining Train
This is the list of all series of RailMac Grout Car Series Underground Mining Train.
RailMac SLSJ-3 Underground Mining Train
RailMac Model: SLSJ-3
Operating Weight: 6T
Track Gauge: 762 or 900 mm
Wheelbase: 1200 mm
Height of Traction: 430 m
Wheel Diameter: 440 mm
