Lithium Battery Locomotive
Lithium battery locomotive adopts lithium battery as power source. Lithium batteries have the characteristics of high energy density, high conversion efficiency, no memory effect, no chargedischarge delay, low self-discharge rate, and wide operating temperature range. In particular, lithium iron phosphate batteries have the advantages of non-toxic, non-polluting, good safety performance, long life and wide sources of raw materials, and long life. Its application on locomotives effectively solves the lead-acid battery problems of requiring frequent maintenance, frequent charging and insufficient cruising range in long tunnels.
With its outstanding performance and reliability, it provides an efficient and environmentally friendly solution for mining transportation. We provide comprehensive life cycle services, from design to power system supply, from installation and commissioning to after-sales service training, as well as spare parts supply and technical support. Welcome to visit our website or contact our sales team for the latest product information and technical support.
General Specifications of Lithium Battery Locomotive Series
| Self-weight: | 15 T - 35 T |
| Track Gauge: | 762/900mm |
| Wheelbase: |
1400mm - 2600mm |
| Min.Turning Curve: |
15m - 25m |
| Wheel Diameter: |
840mm |
| Motor Power: | 30 kW*2 - 110 kW * 2 |
| Battery Capactiy: |
400 - 500 Ah |
| Rated Voltage: | 320 - 537.6 V |
| Houry Traction: | 20.92 - 80 kN |
| Max,Traction: | 39 - 92 kN |
| Houry Speed: |
8.9 - 15 km/h |
Engine Model |
Self-weight |
Track Gauge |
Engine Model |
Adhesive Weight |
Track Gauge |
||
| CTY15/7,9GP | 15 T | 762/900mm | CTY20/7,9GP | 20 T | 762/900mm | ||
| CTY25/7,9GP | 25 T | 762/900mm | CTY30/7,9GP | 30 T | 762/900mm | ||
| CTY35/7,9GP | 35 T | 762/900mm | |||||
| ——END—— | |||||||
RailMac Lithium Battery Locomotive Series Underground Mining Train
This is the list of all series of RailMac Lithium Battery Locomotive Series Underground Mining Train.
RailMac CTY35/7,9GP Underground Mining Train
RailMac Model: CTY35/7,9GP
Self Weight: 35T
Track Gauge: 762 or 900 mm
Wheelbase: 2600 mm
Min.Tuming Curve: 25 m
Wheel Diameter: 840 mm
RailMac CTY30/7,9GP Underground Mining Train
RailMac Model: CTY30/7,9GP
Self Weight: 30T
Track Gauge: 762 or 900 mm
Wheelbase: 2600 mm
Min.Tuming Curve: 25 m
Wheel Diameter: 840 mm
RailMac CTY25/7,9GP Underground Mining Train
RailMac Model: CTY25/7,9GP
Self Weight: 25T
Track Gauge: 762 or 900 mm
Wheelbase: 2600 mm
Min.Tuming Curve: 25 m
Wheel Diameter: 840 mm
RailMac CTY20/7,9GP Underground Mining Train
RailMac Model: CTY20/7,9GP
Self Weight: 20T
Track Gauge: 762 or 900 mm
Wheelbase: 2500 mm
Min.Tuming Curve: 25 m
Wheel Diameter: 840 mm
RailMac CTY15/7,9GP Underground Mining Train
RailMac Model: CTY15/7,9GP
Self Weight: 15T
Track Gauge: 762 or 900 mm
Wheelbase: 1400 mm
Min.Tuming Curve:15 m
Wheel Diameter: 680 mm
